Name: China PE Reducing Tee Manufacturers, Suppliers - Factory Direct Wholesale - DSL Fusion
Brand: DSL Fusion Technology Co., Ltd
SKU: 219491162

product-235-155

SIZE (dn-dn1)	L	L1	L2	H	SDR17	SDR11
T75X32	230	70	45	95	√	√
T75X40	230	70	50	103	√	√
T75X50	230	70	55	110	√	√
T75X63	230	70	63	116	√	√
T90X40	240	79	50	110	√	√
T90X50	240	79	55	110	√	√
T90X63	240	79	63	115	√	√
T90X75	263	79	70	125	√	√
T110X32	263	82	48	115	√	√
T110X40	263	82	49	125	√	√
T110X50	263	82	55	130	√	√
T110X63	263	82	63	135	√	√
T110X75	263	82	70	140	√	√
T110X90	295	82	79	150	√	√
T125X50	265	87	60	140	√	√
T125X63	265	87	63	145	√	√
T125X75	265	87	70	155	√	√
T125X90	280	87	79	160	√	√
T125X110	315	87	82	165	√	√
T140X63	285	92	63	143	√	√
T140X75	290	92	70	155	√	√
T140X90	305	92	79	160	√	√
T140X110	315	92	82	160	√	√
T140X125	333	92	87	172	√	√
T160*50	275	98	55	150	√	√
T160X63	275	98	63	158	√	√
T160X75	288	98	70	168	√	√
T160X90	300	98	79	175	√	√
T160X110	325	98	82	180	√	√
T160X125	335	98	87	190	√	√
T160X140	347	98	92	195	√	√
T180X90	340	105	79	185	√	√
T180X110	355	105	82	190	√	√
T180X125	365	105	87	195	√	√
T180X140	380	105	92	200	√	√
T180X160	400	105	98	203	√	√
T200X63	307	112	63	180	√	√
T200X75	315	112	70	183	√	√
T200X90	334	112	79	192	√	√
T200X110	356	112	82	198	√	√
T200X125	380	112	87	202	√	√
T200X140	400	112	92	207	√	√
T200X160	420	112	98	210	√	√
T200X180	436	112	105	118	√	√
T225X63	355	120	63	190	√	√
T225X75	355	120	70	197	√	√
T225X90	355	120	79	212	√	√
T225X110	375	120	82	215	√	√
T225X125	425	120	87	214	√	√
T225X140	425	120	92	218	√	√
T225X160	425	120	98	228	√	√
T225X180	465	120	105	232	√	√
T225X200	465	120	112	238	√	√
T250X90	395	129	79	225	√	√
T250X110	395	129	82	225	√	√
T250X125	445	129	87	230	√	√
T250X140	445	129	92	235	√	√
T250X160	445	129	98	240	√	√
T250X180	485	129	105	245	√	√
T250X200	485	129	112	252	√	√
T250X225	535	129	120	260	√	√
T280X110	415	139	82	240	√	√
T280X125	465	139	87	245	√	√
T280X140	465	139	92	250	√	√
T280X160	465	139	98	260	√	√
T280X180	505	139	105	265	√	√
T280X200	505	139	112	270	√	√
T280X225	555	139	120	275	√	√
T280X250	555	139	129	285	√	√
T315X90	440	150	79	260	√	√
T315X110	440	150	82	262	√	√
T315X125	485	150	87	262	√	√
T315X140	485	150	92	265	√	√
T315X160	485	150	98	272	√	√
T315X180	530	150	105	280	√	√
T315X200	530	150	112	285	√	√
T315X225	575	150	120	295	√	√
T315X250	575	150	129	302	√	√
T315X280	640	150	139	312	√	√
T355X90	468	164	79	275	√	√
T355X110	468	164	82	276	√	√
T355X125	485	164	87	285	√	√
T355X140	485	164	92	286	√	√
T355X160	485	164	98	295	√	√
T355X180	555	164	105	300	√	√
T355X200	555	164	112	308	√	√
T355X225	610	164	120	315	√	√
T355X280	640	164	139	335	√	√
T355X315	640	130	150	345	√	√
T400X90	495	179	79	300	√	√
T400X110	495	179	82	305	√	√
T400X125	545	179	87	308	√	√
T400X140	545	179	92	310	√	√
T400X160	545	179	98	315	√	√
T400X180	585	179	105	325	√	√
T400X200	585	179	112	335	√	√
T400X225	640	179	120	345	√	√
T400X250	640	179	129	350	√	√
T400X280	675	179	139	360	√	√
T400X315	675	165	150	370	√	√
T400X355	675	145	150	375	√	√
T450X110	435	155	82	365	√	√
T450X160	485	155	115	365	√	√
T450X200	530	155	110	365	√	√
T450X250	580	155	110	375	√	√
T450X315	600	130	140	385	√	√
T450X355	660	140	160	405	√	√
T450X400	720	145	145	405	√	√
T500X110	430	150	80	350	√	√
T500X160	485	150	110	350	√	√
T500X200	520	145	110	400	√	√
T500X250	560	155	110	410	√	√
T500X315	640	145	110	400	√	√
T500X355	610	120	145	470	√	√
T500X400	728	150	150	460	√	√
T500X450	710	115	150	450	√	√
T560X110	410	135	140	445	√	√
T560X160	450	135	140	445	√	√
T560X200	508	135	140	445	√	√
T560X250	545	135	140	445	√	√
T560X315	605	135	145	450	√	√
T560X400	720	135	160	465	√	√
T560X500	825	140	170	475	√	√
T630X110	475	145	135	480	√	√
T630X160	475	140	140	485	√	√
T630X200	550	150	145	490	√	√
T630X250	555	140	145	490	√	√
T630X315	665	150	145	490	√	√
T630X400	725	145	160	505	√	√
T630X450	800	150	180	525	√	√
T630X500	810	145	180	525	√	√
T710X110	500	180	160	520	√	√
T710X160	545	180	160	520	√	√
T710X200	568	180	165	522	√	√
T710X250	630	180	165	522	√	√
T710X315	681	180	165	522	√	√
T710X400	764	180	165	522	√	√
T710X500	864	180	165	522	√	√
T710X630	983	180	165	525	√	√
T800X110	505	185	170	573	√	√
T800X160	550	185	170	573	√	√
T800X200	606	185	170	573	√	√
T800X250	630	185	170	573	√	√
T800X315	719	185	170	573	√	√
T800X400	802	185	170	573	√	√
T800X500	902	185	170	573	√	√
T800X630	1031	185	170	573	√	√
T800X710	1100	185	170	573	√	√
