Butt fusion welding machine
Butt fusion welding machine is a special welding equipment that uses hot-melt butt technology to weld thermoplastic pipe fittings.
The welding frame of the butt fusion welding machine is separated from the operating system.
The whole butt fusion welding machine (automatic type, hydraulic semi-automatic type) is composed of hydraulic operating console, welding frame and fixture, electric heating plate, electric milling cutter and other parts.
Specification
|
Product Name |
butt fusion welding machine |
|
Product Model |
DH315 |
|
Fuse Range |
90-315mm |
|
Input Voltage |
220V±10% 50/60Hz |
|
SDR |
SDR9 to SDR41 |
|
Heater Temp |
0℃~270℃(±7℃) |
|
Heater Power |
3.0KW |
|
Facer Power |
1.1KW |
|
Hydraulic Power |
0.75KW |
|
Applied Material |
PE,PP,PVDF |
|
Weight |
217kg |
|
Tool bag |
tools,bolts,selected spare parts,etc |
ISO21307:2011(E) and DVS2207/1(08/2007)
Characteristics
The main electrical components are imported or domestic best components.
The hydraulic seal system adopts imported products. Fast joint adopts flat mouth type, more environmental protection and more durable.
The electric heating plate adopts PTFE coating, good stability and independent temperature control system. temperature difference control to domestic machine minimum range.
The milling cutter adopts the strong motor, the special material blade, makes the cutting effect more perfect.
The hydraulic station is equipped with accumulator, the valve used is imported product, the machine fixture is wide fixture, the aviation plug is imported, and the frame has a hook design.
Product Display
Our Factory
DSL Fusion Technology is a China-thailand joint venture company, has been a key player in the field of supplying plastic pipe welding machinery for 8 years.To gain a good reputation,DSL team not only provide good quality machinery,but also provide plastic pipe welding technology, design,training and aftersale service to our clients. In the past 8 years,with our quality products and good service,we now export a Chinese-engineered plastic pipe welding machinery range to 70 countries worldwide.
Why Choose Us?
our device has the following characteristics:
The only updates the equipment for five generations development process.
The only use of advanced technology from Germany.
The only electrical integration automated system.
The only design.
The only practical new technology.
